PixaarNext's The Workstations

We are proud to announce that PixaarNext's is introducing it's a new entrant in int's product range - The Workstations further strengthening its position and in line with our commitment to the Central Government's'Make in India' initiative. A workstation is a computer intended for individual use that is faster and more capable than a personal computer. It's intended for business or professional use (rather than home or recreational use). Workstations and applications designed for them are used by small engineering companies, architects, graphic designers, and any organization, department, or individual that requires a faster microprocessor, a large amount of random access memory (RAM), and special features such as high-speed graphics adapters. Local area network (LAN) that in turn shares the resources of one or more large computers. Since they are PCs, they can also be used independently of the mainframe assuming they have their own applications installed and their own hard disk storage.

Parameter Intel Based
Operating Systems Windows 10/11 Professional 64 Bit Ubuntu, RHEL
Processor Family Intel core Family FLGA 1700 Socket, 12th / 13th / 14th Generation
Processor Support Intel Core i9 12900, Intel Core i9 12900k, Intel Core i9 13900, Intel Core i9 13900K, Intel Core i9 14900, Intel Core i9 14900k
Chipset Intel Xeon Q670 / Z790 / W680 support FCLAG 1700 Soc
Form Factor Tower
Maximum Memory Support "4*DDR5/DDR4 UDIMM slots for up to 128GB capacity Supporting2666,3200,4000;4800,5200,5600 MHz " "
Memory DIMM 4 DIMM
Internal Storage 4 Bay Combo of 3.5/2.5" with 1TB upto 4TB SATA HDD/SATA SSD Support; 2/3 M.2 NVMe Storage 2/3*2 TB PCIe® NVMe™ M.2 SSD
Optical Drive 48x Optical DVD Writer (Optional)
Available Graphics Integrated:Intel® UHD Graphics 730; Intel® UHD Graphics 770 Dedicate: Nvidia Quadro/GeForce Series GPU up to 48GB
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Supports up to 24-Bit/192 kHz playback"
Wireless Technologies (Optional) Intel® Wi-Fi 1800 and Bluetooth® 5.2 wireless PCI cardIntel Wi-Fi 6 AX200 and Bluetooth® 5.2 wireless PCI card,
Expansion Slot "Q670: 2 M.2 2280; 1 PCIe 3 x1; 2 PCIe 4 x16; W680:1*PCIe x16 slot with PCIe 5.0 for up to 64GB/s;1*PCIe x16 slot with PCIe 4.0 for up to 8GB/s; 1*PCIe x4 slot with PCIe 4.0 for up to 8GB/s;2*PCIe x4 slot with PCIe 3.0 for up to 4GB/s 2*Standard PCI slots (32bit); Z790: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4);1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4)2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3) "
Ports and connectors "Front: 1 USB 2.0; 1 USB 3.0; 1 headphone; 1 microphone Rear: Q670;2 USB 2.0;2 UEB 3.1 Gen1;1 type C;1HDMI;1VGA/DP; 1 LAN1 GbE W680 2 USB 3.2 GEN ;8 USB 3.1 Gen1; 1 HDMI; 1DVI; 2 DP; 2 lan 2.5GbE Z790:1 USB 3.2 Gen2;4 USB 3.2 Gen1;4 USB 2.0;1 HDMI;1 DP; 1 RJ45"
Input device USB Wired Standard Keyboard; USB 1000 DPI Optical Mouse
Communications LAN Integrated Intel® I219LM GbE 10/100/1000 GBPS
Drive Bays 4 Bay Combo of 3.5/2.5" ; 2/3 M.2 NVMe
Environmental Operating temperature: 10 to 405°C; Operating humidity: 10 to 90% RH
Security management H/W Lock;Trusted Platform Module TPM 2.0 Security Header Kensington Lock slot (Optional); intrusion Mechanical Sensor (optional)
Power 450/550/700 W internal power supply, up to 80+/80+ Gold efficiency
Certification/compliance "ROHS, FCC, BIS, EPR , Windows H/W certificate, ISO 27001, ISO 14001, ISO 9001,ISO 20000-1, ISO-50001"
Dimensions 447 x 200 x 428mm
Display "23.8,27 Inch , FHD 1920*1080 resolution with standard/Highe Adjustabel Foot 23.8 inch, FHD 1920*1080 resolution with integrated Web Camera, 2 Speaker 27""/32""/34""/43""/49"" Flat/Curve 2K/4K resolution (Viewsonic/Samsung Make)"

Parameter Model : Zero Silver-W
Operating Systems Windows 10/11 Professional 64 Bit Ubuntu, RHEL
Processor Family Intel Xeon W Series FCLGA 2066 Soc 2nd Processor
Intel Xeon W Series FCLGA 4677 Soc 3rd Generation
Processor Support Intel Xeon W 2245, Intel Xeon W 2255, Intel Xeon W 2265, Intel Xeon W 2275, Intel Xeon W 2295;Intel Xeon W3 2423, Intel Xeon W3 2425, Intel Xeon W3 2435, Intel Xeon W5 2445 Intel Xeon W5 2455X, Intel Xeon W5 2465X,Intel Xeon W7 2475X, Intel Xeon W7 2495X, Intel Xeon W5 3425, Intel Xeon W5 3435x, Intel Xeon W73445, Intel Xeon W73455, Intel Xeon W9 3475X, Intel Xeon W9 3495X, Intel Xeon W5 3525, Intel Xeon W5 3535X
Chipset Intel C422 Support FCLGA 2066 Soc / W790 Chipset support FCLGA 4677 Soc
Form Factor Tower
Maximum Memory Support C422: 8 x DIMM, Max. 512GB, DDR4 2666/2400/2133 MHz RDIMM, LR-DIMM Memory *1;Quad Channel Memory Architecture W790:8 x DIMM slots DDR5 memory supported only;4-channel memory architecture RDIMM up to 64GB supported 3DS RDIMM up to 256GB supported;Memory speed: Up to 4800 MT/s (1DPC), 4400 MT/s
Memory DIMM 8 DIMM
Internal Storage 8 x SATA III 6Gb/s ports with 2 x SATA DOM supported Storage supported uptp 4*8TB SATA HDD 3 x M.2; 1 x U.2 Sturage Support
Optical Drive 48x Optical DVD Writer (Optional)
Available Graphics Dedicate: Nvidia Quadro/GeForce Series GPU up to 48GB
Audio Realtek® ALC1150 HD audio codec Supports 7.1 channel configurations;Realtek® ALC S1220A 8-Channel High Definition Audio CODEC featuring Crystal Sound 3; Realtek® ALC897 HD Audio Codec Supports 2/4/5.1/7.1 channel configurations 3 x Audio Jacks (Audio in/Audio out/Mic)
Wireless Technologies (Optional);Intel® Wi-Fi 1800 and Bluetooth® 5.2 wireless PCI cardIntel Wi-Fi 6 AX200 and Bluetooth® 5.2 wireless PCI card
Expansion Slot op1:2 x PCIe 3.0 x16 (x16 mode);2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8);1 x PCIe 3.0 x4 (x4 mode) op2:1 x PCIe x16 (Gen3 x16 bus) slot; 1 x PCIe x16 (Gen3 x0 or x8 bus) slot; 1 x PCIe x16 (Gen3 x16 or x8 bus) slot; 1 x PCIe x16 (Gen3 x0 or x8 bus) slot; 1 x PCIe x16 (Gen3 x16 or x8 bus) slot; 1 x PCIe x16 (Gen3 x0 or x8 bus) slot,; 1 x PCIe x16 (Gen3 x16 or x8 bus) slot
Ports and connectors Front: 1 USB 2.0; 1 USB 3.0; 1 headphone; 1 microphone C422:1 x PS/2;8 x USB 3.0;2 x USB 3.1 Type-A and Type-C 2 x RJ45;5 x Audio jacks;1 x Optical S/PDIF-Out W790:1 x USB 3.2 Gen2x2 (Type-C);5 x USB 3.2 Gen2x1;(Type-A);1 x VGA;1 x COM;2 x RJ45;1 x MLAN;3 x Audio jacks;1 x ID button with LED
Input device USB Wired Standard Keyboard; USB 1000 DPI Optical Mouse
Drive Bays 4 Bay Combo of 3.5/2.5" ; 1 M.2 NVMe
Environmental Operating temperature: 10 to 405°C; Operating humidity: 10 to 90% RH
Security management H/W Lock;Trusted Platform Module TPM 2.0 Security Header Kensington Lock slot (Optional); intrusion Mechanical Sensor (optional)
Power 550/700/1000/1200/1500 W internal power supply, up to 80+/80+ Gold efficiancy
Certification/compliance ROHS, FCC, BIS, EPR , Windows H/W certificate, ISO 27001, ISO 14001, ISO 9001,ISO 20000-1, ISO-50001
Dimensions 447 x 200 x 428mm
Display 23.8,27 Inch , FHD 1920*1080 resolution with standard/Highe Adjustabel Foot 23.8 inch, FHD 1920*1080 resolution with integrated Web Camera, 2 Speaker 27"/32"/34"/43"/49" Flat/Curve 2K/4K resolution (Viewsonic/Samsung Make)

Parameter Model : Zero Silver-C
Operating Systems Windows 10/11 Professional 64 Bit Ubuntu, RHEL
Processor Family Intel core Family FLGA 1200/1700 Socket,
11th / 12th / 13th / 14th Generation
Processor Support Intel Core i5 12500; Intel Core i5 13500; Intel Core i5 13600K Intel Core i7 11700; Intel Core i7 11700K; Intel Core i7 12700; Intel Core i7 12700k; Intel Core i7 13700; Intel Core i7 13700k; Intel Core i9 12900; Intel Core i9 12900k;Intel Core i9 13900; Intel Core i9 13900K;Intel Core i9 14900; Intel Core i9 14900k
Chipset Intel Xeon B560/B760/Q670 / Z790 / W680 support FCLAG 1700 Soc
Form Factor DesktopTower
Maximum Memory Support 4*DDR4/DDR5 UDIMM slots for up to 128GB capacity Supporting 3200/4000;4800;5200 MHz
Memory DIMM 2/4 DIMM
Internal Storage 4 Bay Combo of 3.5/2.5" with 1TB upto 4TB SATA HDD/SATA SSD Support; 2/3 M.2 NVMe Storage 2/3*2 TB PCIe® NVMe™ M.2 SSD
Optical Drive 48x Optical DVD Writer (Optional)
Available Graphics Integrated:Intel® UHD Graphics 730; Intel® UHD Graphics 770 Dedicate: Nvidia Quadro/GeForce Series GPU up to 48GB
Audio Realtek 7.1 Surround Sound High Definition Audio CODEC Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Supports up to 24-Bit/192 kHz playback"
Wireless Technologies (Optional) Intel® Wi-Fi 1800 and Bluetooth® 5.2 wireless PCI cardIntel Wi-Fi 6 AX200 and Bluetooth® 5.2 wireless PCI card
Expansion Slot B760: 2 M.2 2280; 2 PCIe 3X1; 1 PCIe 4 x16; 1 PCIe 3 x16 Q670: 2 M.2 2280; 2 PCIe 3 x1;12 PCIe 4 x16; 1 M.2 2230 Type E W680:1*PCIe x16 slot with PCIe 5.0 for up to 64GB/s;1*PCIe x16 slot with PCIe 4.0 for up to 8GB/s; 1*PCIe x4 slot with PCIe 4.0 for up to 8GB/s;2*PCIe x4 slot with PCIe 3.0 for up to 4GB/s 2*Standard PCI slots (32bit); DATA Z790: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4);1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1_4)2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_2, PCIEX1_3)
Ports and connectors Front: 1 USB 2.0; 1 USB 3.0; 1 headphone; 1 microphone Rear: B760; 4 USB 2.0; 1 USB 3.2 Gen2; 1 USB Type C; 1 RJ Rear: Q670;2 USB 2.0;2 UEB 3.1 Gen1;1 type C;1HDMI;1VGA/DP; 1 LAN1 GbE W680 6 USB 3.2 GEN ;4 USB 3.1 Gen1; 1 HDMI; 1DVI; 2 DP; 2 lan 2.5GbE Z790:1 USB 3.2 Gen2;4 USB 3.2 Gen1;4 USB 2.0;1 HDMI;1 DP; 1 RJ45
Input device USB Wired Standard Keyboard; USB 1000 DPI Optical Mouse
Drive Bays 4 Bay Combo of 3.5/2.5"; 2/3 M.2 NVMe
Environmental Operating temperature: 10 to 405°C; Operating humidity: 10 to 90% RH
Security management H/W Lock; Trusted Platform Module TPM 2.0 Security Header Kensington Lock slot (Optional); intrusion Mechanical Sensor (optional)
Power 450/550/700 W internal power supply, up to 80+/80+ Gold efficiency
Certification/compliance ROHS, FCC, BIS, EPR, Windows H/W certificate, ISO 27001, ISO 14001, ISO 9001,ISO 20000-1, ISO-50001
Dimensions 447 x 200 x 428mm
Display 23.8,27 Inch, FHD 1920*1080 resolution with standard/Highe Adjustable Foot 23.8 inch, FHD 1920*1080 resolution with integrated Web Camera, 2 Speaker 27"/32"/34"/43"/49" Flat/Curve TCO FHD/2K/4K resolution (Benq/Viewsonic/Samsung Make)

Parameter Model : Zero Silver-SG
Operating Systems Windows 10/11 Professional 64 Bit Ubuntu, RHEL
Processor Family Intel Xeon Scalable Silver/Gold Series 2nd Generation FCLGA 3647 Soc
Intel Xeon Scalable Silver/Gold Series 2nd Generation FCLGA 4189 Soc
Processor Support 2nd Generation Intel Xeon Silver 4210r Intel Xeon Silver 4212, Intel Xeon Silver 4214, Intel Xeon Silver 4214r, Intel Xeon Silver 4216; 3rd Generation Intel Xeon Silver 4310, Intel Xeon Silver 4314, Intel Xeon Silver 4316; 2nd Generation Intel Xeon Gold 5218r, Intel Xeon Gold 5230, Intel Xeon Gold 6226, Intel Xeon Gold 6230R, Intel Xeon Gold 6248, Intel Xeon Gold 6242r, 3rd Generation Intel Xeon Gold 6326, 3rd Generation Intel Xeon Gold 6334, 3rd Generation Intel Xeon Gold 6338, 3rd Generation Intel Xeon Gold 6348
Chipset Intel C621 / Intel C621A supporting 1P/2P
Form Factor Tower 1P/2P
Maximum Memory Support C621/C621A 1P:8 x DIMM slots DDR4 memory supported only 6-channel memory architecture RDIMM up to 128GB supported' LRDIMM up to 128GB supported Memory speed: 2933/2666/2400/2133 MT/s C621/C621A 2P:12 / 16 x DIMM slots DDR4 memory supported only 6-channel memory architecture RDIMM up to 128GB supported LRDIMM up to 128GB supported Memory speed: 2933/2666/2400/2133 MT/s
Memory DIMM 8/12/16 DIMM
Internal Storage 3 x SlimSAS connectors for 12 x SATA 6Gb/s; 2 x SATA 6Gb/s ports supporting SATA DOM; 2 x SlimSAS connectors for 2 x Gen3 NVMe Total support 4*1/2/4/8 TB SATA HDD;2*M.2 NVME 256GB/512GB/1TB/2TB Storage
Optical Drive 48x Optical DVD Writer (Optional)
Available Graphics Dedicate: Nvidia Quadro/GeForce Series GPU up to 48GB
Audio Dedicated Sound 7.1 Card (Optional)
Wireless Technologies (Optional); Intel® Wi-Fi 1800 and Bluetooth® 5.2 wireless PCI cardIntel Wi-Fi 6 AX200 and Bluetooth® 5.2 wireless PCI card,
Expansion Slot C621/C621a 1P: 3 PCIe x16 Gen3 ;3 PCIe x16 (Gen3 x8); 1 PCIe x4 (Gen3 x4) C621/C621A 2P: 3 PCIe x16 (Gen3 x16) ;2 PCIe x8 (Gen3 x8) ; 1 PCIe x8 (Gen3 x4) slot, from PCH
Ports and connectors C621/C621A 1P;Front: 1 USB 2.0; 1 USB 3.0; 1 headphone; 1 microphone;Rear:4 x USB 3.0;1 x VGA;1 x COM;2 x RJ45;1 x MLAN;1 x ID button with LED C621/C621A Rear:2 x USB 3.0;1 x VGA;1 x RJ45 serial port;4 x RJ45;1 x MLAN;1 x ID button with LED, 2 x 10Gb/s BASE-T LAN ports (Intel® X710-AT2) (Optional)
Input device USB Wired Standard Keyboard; USB 1000 DPI Optical Mouse
Drive Bays 4 Bay Combo of 3.5/2.5"; 2 M.2 NVMe
Environmental Operating temperature: 10 to 405°C; Operating humidity: 10 to 90% RH
Security management H/W Lock;Trusted Platform Module TPM 2.0 Security Header Kensington Lock slot (Optional); intrusion Mechanical Sensor (optional)
Power 550/700/1000/1200 W internal power supply, up to 80+/80+ Gold efficiency (Single/RPS)
Certification/compliance ROHS, FCC, BIS, EPR , Windows H/W certificate, ISO 27001, ISO 14001, ISO 9001,ISO 20000-1, ISO-50001
Dimensions 1 P; 447 x 200 x 428mm;2 P; 553 x 198 x 425mm
Display 23.8,27 Inch , FHD 1920*1080 resolution with standard/Highe Adjustabel Foot 23.8 inch, FHD 1920*1080 resolution with integrated Web Camera, 2 Speaker 27"/32"/34"/43"/49" Flat/Curve FHD TCO 2K/4K resolution (BenqViewsonic/Samsung Make)

Our Products are available on GeM portal As well.

Our products are qualified and satisfy Indian government procurement compliances and being listed in the procurement portal GEM.
